Description:
□ Loose tube cable with non-metal central strength member, and polyethylene coated steel armour
□ Cable consists of six loose tubes (or some fillers) stranded around the non-metal central strength member.
□ All the interstices of cable core are filled with water blocking compound.

Characteristics:
□ Accurate fiber excess length ensures good mechanical and temperature performance.
□ The central strength member is made of high Young's modulus glass fiber reinforced plastic rod (FRP)
□ The non-metal central strength member avoids breakdown between central strength member and steel tape caused by lightning induction.
□ The loose tubes are filled with special filling compound for crucial protection of the optical fibers.
□ Complete water blocking construction ensures good water blocking and moisture-proof performance.
□ Strictly control of production process and raw materials.
□ The longitudinal binding steel tape functions as protection as well as reinforcing the crush resistance and mechanical performance.
□ The outer sheath possesses good ultra violet radiation resistant property.

Applications:
Outdoor communication, long distance and Local Area Network (LAN) communication

Cable specifications:

Outer Diameter: 12.6 - 18.0 mm

Weight: 130 kg - 300 kg

Laying method: Aerial

Temperature range: -40℃~+70℃

Fiber count: 2 - 144
